Specifikationer for APLX-75-EU-1
Audio
Built-in speaker(s)
YesNumber of built-in speakers
2Speaker power
10 WBattery
Battery Type
UN3091 – Lithium METAL inside equimentLithium Weight (g)
0,064 gDisplay
Accuracy touch
1 mmBrand specific technologies
Promethean Vellum Touch TechnologyContrast ratio (dynamic)
5000:1Contrast ratio (typical)
1200:1Display brightness
350 cd/m²Display diagonal
75 ”Display number of colours
1.07 billion coloursDisplay resolution
3840 x 2160 pixelsHD type
4K Ultra HDLED backlight
YesLED backlighting type
Direct-LEDLow Blue Light technology
YesMaximum refresh rate
60 HzNative aspect ratio
16:9Number of simultaneous touchpoints
20Palm erase
YesPalm rejection
YesPanel type
TFTPen & touch differentiation
YesResponse time
8 msScreen glass thickness
3,2 mmSurface material
Tempered glassTouch resolution
32768 x 32768 pixelsTouch system response time
10 msTouch technology
Multi-touchTouchscreen
YesViewing angle, horizontal
178 °Viewing angle, vertical
178 °Working area
1652 x 930 mmErgonomics
Certification
FCC, IC, UL, CUL, CB, RCMFanless
YesPanel mounting interface
800 x 400 mmPower cable length
3 mProduct colour
BlackVESA mounting
YesWall mountable
YesFeatures
Accuracy touch
1 mmBrand specific technologies
Promethean Vellum Touch TechnologyContrast ratio (dynamic)
5000:1Contrast ratio (typical)
1200:1Display brightness
350 cd/m²Display diagonal
75 ”Display number of colours
1.07 billion coloursDisplay resolution
3840 x 2160 pixelsHD type
4K Ultra HDLED backlight
YesLED backlighting type
Direct-LEDLow Blue Light technology
YesMaximum refresh rate
60 HzNative aspect ratio
16:9Number of simultaneous touchpoints
20Palm erase
YesPalm rejection
YesPanel type
TFTPen & touch differentiation
YesResponse time
8 msScreen glass thickness
3,2 mmSurface material
Tempered glassTouch resolution
32768 x 32768 PixelsTouch system response time
10 MillisecondTouch technology
Multi-touchTouchscreen
YesViewing angle, horizontal
178 °Viewing angle, vertical
178 °Working area
1652 x 930 mmLegal Information
UNSPSC Code (Icecat)
44111911Network
Ethernet LAN
YesEthernet LAN data rates
10/100/1000 Mbit/sWake-on-LAN ready
YesOperational conditions
Operating relative humidity (H-H)
20 – 80 %Operating temperature (T-T)
0 – 40 °CStorage relative humidity (H-H)
20 – 90 %Storage temperature (T-T)
-15 – 55 °CPackage dimensions
Depth (package,cm)
20 cmGross Weight (Package, kg)
64,5 kgHeight (package,cm)
186 cmWidth (package,cm)
113 cmPackaging content
Batteries included
YesCables included
AC/HDMI/USB Type-A to USB Type-B/USB Type-CNumber of stylus pens
2Pen tray included
YesQuick start guide
YesRemote control included
YesStylus tip diameter
3 mmPackaging data
Quantity per pack
1 pc(s)Performance
Ambient light sensor
YesPorts & interfaces
Audio output
1Ethernet LAN (RJ-45) ports
2HDMI ports quantity
3HDMI version
2.0Headphone connectivity
3.5 mmMicrophone connectivity
3.5 mmOPS slot
1RS-232 ports
1USB 2.0 ports quantity
3USB 2.0 Type-B Touch ports quantity
2USB connector type
USB Type-AUSB Type-C ports quantity
1VGA (D-Sub) ports quantity
1Power
AC input frequency
50 – 60 HzAC input voltage
100 – 240 VPower consumption (standby)
0,5 WPower consumption (typical)
132 WProduct dimensions
Net Weight (Product, kg)
50 kgProduct Depth
11 cmProduct Height
171,6 cmProduct Width
103,3 cmProjector
Built-in projector
NoSustainability
Compliance certificates
CESustainability certificates
ENERGY STARSustainability compliance
YesSystem requirements
Linux operating systems supported
YesMac compatibility
YesMac operating systems supported
YesWindows operating systems supported
YesTechnical details
Compliance certificates
CEVendor information
Brand Name
PrometheanWarranty
5 År
