Specification
Show allHide all
Display
Back light
Direct type LED
Size (diagonal)
86″
Resolution
3840×2160
Brightness
450
Contrast ratio (dynamic)
4,000:1
Viewing angle
178°
Response time
8ms
Life
50,000 hours
Display colours
1,070
Speaker count
2
Watts per speaker
20W
Surface hardness
7H
Glass
Anti Glare + Anti Finger Print
Haze
25%
Ambient light sensor
Yes
Air gap
0.60mm
Pencil hardness
9H
Physical spec
Dimensions (W x D x H) mm
1952 x 111 x 1165
Wall-hanging screw spec
M8*25mm
VESA holes
800*400
In the box
European Standard Power Cord 3M
American Standard Power Cord 3M
British Standard Power Cord 3M
USB Touch Cable 3M
USB-C Cable 2M
HDMI Cable 3M
Writing Pen x2
Remote Control
Battery
QSG
Connections
Inputs 3 x HDMI 2.0, 1 x VGA, 1 x DisplayPort, 1 x Audio 3.5mm, 1 x USB-A 2.0, 4 x USB 3.0, 1 x RJ45, 2 x USB-C, 1 x Microphone, 1 x OPS slot
Outputs 1 x HDMI 2.0, 1 x S/PDIF, 1 x Audio 3.5mm, 1 x RJ45
Control 2 x USB-B interactive, 1 x RS232
Bezel size (top)
28.60mm
Bezel size (bottom)
0.00mm
Bezel size (left)
28.60mm
Bezel size (right)
28.60mm
Operating conditions
20% ~ 93% RH
Operating temperature (max)
40°C
Net weight
59.5 kg
Gross weight
73.8 kg
Wireless – technology
Wifi 6, 2.4G/5G, 2T2R, BT5.2 (AZ932-HNG optional)
Wireless – operating frequency
2.4G/5G
Touch system
System
Windows 7/8/10/WindowsXP/11/Linux/Mac/Android
Touch accuracy
<1.00mm
Touch point
40 android / 50 windows
Touch tool
Finger, Passive infrared pen
Pen/finger detection
Yes
Touch response
<3.3ms
Power
Power supply
100-240V~ 50/60Hz 3.5A
Power consumption (standby)
0.5W
Power consumption (max)
450W
Power consumption – average (watts)
350
Power consumption – Energy Star (watts)
170.3
Operation System
System version
Android 14
CPU
Octa-core A72 x4 + A53 x4
GPU
G52 MC3
RAM
8GB
Storage
64GB
OSD / display languages
20 languages: Arabic, Czech, Danish, Dutch, English, Finnish, French, German, Greek, Italian, Norwegian, Polish, Portuguese, Romanian, Russian, Chinese (simplified), Spanish, Swedish, Chinese (traditional), Turkish
