Specifikationer for 60004120
Battery
Battery Type
ALKALINE – Alkaline Batteries – No restictionsDesign
Placement
DesktopProduct colour
WhiteProduct type
Large venue projectorDisplay
Built-in display
NoFeatures
Certification
UL60950-1, FCC 15 B (ANSI C63.4.2014), CAN/CSA C22.2 No.60950-1-07, ICES-003 6 (ANSI C63.4:2014)Composite sync
YesHDCP
YesNoise level
39 dBNoise level (economic mode)
33 dBSeparate H/V sync
YesSync-on-green (SOG)
YesLamps
Bulb power
370 WLamps quantity
1 lamp(s)Service life of lamp
4000 HourService life of lamp (economic mode)
5000 HourLegal Information
EU ECCN Code
N/AUNSPSC Code (Icecat)
45111609US ECCN Code
EAR99Lens system
Focus
AutoHorizontal lens shift range
-0.3 – 0.3 °Number of optional lenses supported
8Vertical lens shift range
-0.1 – 0.6 °Light source
Lamp power
370 WLamps quantity
1 lamp(s)Light source type
LampService life of light source
4000 hService life of light source (economic mode)
5000 hMultimedia
Built-in speaker(s)
YesRMS rated power
10 WNetwork
Ethernet LAN
YesEthernet LAN (RJ-45) ports
1Wi-Fi
NoOperational conditions
Operating relative humidity (H-H)
20 – 80 %Operating temperature (T-T)
5 – 40 °CStorage temperature (T-T)
-10 – 50 °COther features
RS-232 ports
1Package dimensions
Depth (package,cm)
60 cmGross Weight (Package, kg)
12,58 kgHeight (package,cm)
25 cmWidth (package,cm)
49 cmPackaging content
Batteries included
YesCables included
ACManual
YesQuick start guide
YesRemote control included
YesPorts & interfaces
AC (power) in
YesAudio (L/R) in
0Component video (YPbPr/YCbCr) in
0DisplayPorts quantity
1DVI port
NoHDBaseT port
YesHDMI connector type
Full-sizeHDMI ports quantity
2PC Audio in
YesPC Audio out
YesRemote (IR) output
1S-Video inputs quantity
0Serial interface type
RS-232USB 2.0 ports quantity
1VGA (D-Sub) ports quantity
1Power
AC input frequency
50 – 60 HzAC input voltage
100 – 240 VPower consumption (economy mode)
390 WPower consumption (standby)
0,7 WPower consumption (typical)
506 WPower source
ACProduct dimensions
Net Weight (Product, kg)
10,2 kgProduct Depth
41,1 cmProduct Height
16,8 cmProduct Width
50,3 cmProjector
Contrast ratio (typical)
8000:1Horizontal synchronization (max)
153 kHzHorizontal synchronization (min)
15 kHzKeystone correction, horizontal
-40 – 40 °Keystone correction, vertical
-30 – 30 °Matrix size
0,67 ”Native aspect ratio
16:10Projection distance
0.74 – 20.9 mProjection technology
LCDProjector brightness
6500 ANSI lumensProjector native resolution
1080p (1920×1080)Screen size compatibility
40 – 500 ”Vertical synchronization (max)
120 kHzVertical synchronization (min)
24 kHzSoftware
Mac compatibility
YesStorage
Card reader integrated
NoVendor information
Brand Name
Sharp/NECHomepage
http://www.nec-display-solutions.comWarranty
3 ÅrVideo
3D
NoAnalog signal format system
NTSC/NTSC 4.43/PAL/PAL 60/PAL M/PAL N/SECAMFull HD
YesSupported graphics resolutions
1024 x 768 (XGA)/1280 x 1024 (SXGA)/1400 x 1050 (SXGA+)/1600 x 1200 (UXGA)/1920 x 1080 (HD 1080)/1920 x 1200 (WUXGA)/2560 x 1600 (WQXGA)/4096 x 2160/640 x 480 (VGA)/800 x 600 (SVGA)Supported video modes
1080i/1080p/2160p/480i/480p/576i/576p/720p
